Quick Details

  • Products Status: Stock
  • Type: All-In-One
  • Screen Size: 15"
  • Processor Brand: Intel
  • Memory Capacity: 2GB
  • Hard Drive Capacity: 32G
  • Graphics Card Type: Integrated Card
  • Display Type: LED
  • Widescreen: No
  • Processor Main Frequency: Celeron 1.8G
  • Brand Name: MapleTouch
  • Model Number: pos156
  • Place of Origin: Guangdong, China (Mainland)
  • Motherboard: Mini-Intel 1037U
  • size: 15''
  • Color: Black
  • panel: relating capacitive touch
  • Touch Point: 2 or 10
  • Interface: 4*RS232 5*USB 1*VGA 1*LPT 1*LAN
  • install way: tablet and wall mounting
  • Housing: Full metal-Aluminum

Packaging & Delivery

Packaging Details: carton
Delivery Detail: 2-5days

Company Information



We are a manufacturerer with over 12years in production touch screen products, pos system,  work in Alibaba as a golden vip supplier over 6years, and keeping to join HK TDC ICT Fair for 4years, all of products were got FCC,CE,CB,RoHS certificate.





Main Technical Parameters:

Size

15”

Resolution

1024*768

Brightness

250cd/M2

Color

16.7M

Contrast Ratio

600:1

Touch system



Multi point capacitive touch screen MapleTouch-J five line military resistance touch screen (single point up to 35000000 times) (USB/RS232 touch card optional)

System Parameters

Host board

Mini-ITX MP-1037U

CPU

Intel® Celeron® Processor 1037U 1.8G

RAM

2GB DDR3-1333 SDRAM

Chipset

Intel® NM70 Express Chipset

SATA

1×SATA II 3GB/s HDD/SDD/1×SATA III 6GB/s HDD/SDD/1×M-SATA

LAN

1×Realtek RTL8111DL (100/1000Mbps)

Audio

Realtek ALC887 HD Audio Codec integrated

Hard disk

1×2.5 " SATA II HDD-320G/SSD-32G

The output/Input port

2×RS232     4×USB 2.0       1×VGA     1×Audio Out        1×MIC In    1×LPT           1×PS2(KB/MS)

The expansion bus

1×PCI Express×1    1×Mini PCIE

Work Condition

Operating

-10~60°C

Storage temperature

-30~80°C

Humidity

20~85%

Knock and collision

Operating 20G(11Ms),Non-operating 320G with HDD

Operating 80G(11Ms),Non-operating 32G with SSD

Others

Power input

100-240VAC ~ 50~60HZ 1.5A

Power output

12VDC  5A MAX

Material structure

Aluminum

Installation

Hanging type/desktop/VESA cantilever installation

N.W/G.W

5.65KG/3.9KG

Dimension

350mm*234mm*268mm
